SPECIAL
FEATURES : |
| * Heavy
swan-neck frame to eliminate all vibrations and to provide rigidity and
sturdity to the machine. |
| * Table with
telescopic motion in bearings. |
| * Sanding
shoe type parallelogram. |
| * Up and
down movement of the table is provided. |
| * Dust
Collector fitted on the machine. |
| |
|
TECHNICAL
SPECIFICATIONS: |
| - Table Size |
: |
2440 x 1220mm |
| - Sanding Speed |
: |
15 (m/Sec) |
| - Belt Size |
: |
152 x 7000mm |
| - Roller Speed
|
: |
1420 r/min |
| - Installed Power
|
: |
3.7 KW |
| - Overall Size (L x W x
H) |
: |
4300 x 700 x 1400mm |
| - Net Weight |
: |
565 KG |
| |
: |
|
|
STANDARD
ACCESSORIES SUPPLIED WITH THE MACHINE: |
| a)
Appropriate spanners |
1 Set |
| b)
Appropriate size Allen Keys |
1 Set |
| c) Electric
equipment with overload |
1 Set (fitted on the
machine) |
| protection
and emergency switch. |
|
| |
